Φ16 H6 Series HA□S Type Selector Switch (Round Type)

Φ16 H6 Series HA□S Type Selector Switch (Round Type)

Ready Stock JP

ⓘ

Produk tersedia di Jepang. Estimasi sampai Indo dalam 3-5 minggu.
Rp600.000
SKU: WTJ0826-231 Kategori: Tag: Stock:
Produk tersedia di Jepang. Estimasi sampai Indo dalam 3-5 minggu.
Contents 1 piece
Number of notches 2
Contact configuration 2c
Order code 60029261
Part Number HA1S-2C6
—
Mounting hole diameter (Φmm)16.2 (0-0.2)
protective structureIP65
Terminal shapeSoldering tab terminals
Notch angle (°)90
Number of notches2
Contact configuration2c
Rated insulation voltage (V)250
Operation methodStop at each position (manual)
Storage temperature (℃)-30 to 80 degrees Celsius (but not so cold that it freezes).
Insulation resistance (MΩ)100 or more (DC500V megohm)
Operating ambient temperature (°C)-25 to 55 degrees Celsius (but not so cold that it freezes).
Contact resistance (mΩ)50 or less (initial value)
Vibration resistance (durability)5 to 55Hz, single amplitude 0.5mm
Vibration resistant (malfunction resistant)5 to 55Hz, single amplitude 0.5mm
Contact materialsilver
Rated current (A)5
Operation part shapeRound shape (arrow-shaped handle)
Control colorBlack (Direction indicator cap: White)
Withstand voltage (V/min)Switch section: AC2500 (between charging section and ground), AC2500 (between opposite polarity terminals), AC1000 (between same polarity terminals)
Bezel size (mm)Φ24
Ambient humidity during use (%RH)30-85°C (but no condensation)
Mechanical life (10,000 times)25 or older
Electrical lifespan (10,000 cycles)10 or more (open/close frequency of 1200 times/hour)
Shockproof (malfunction) (m/ s² )100
Impact resistance (durability) (m/s 2 )1000
Berat0,15 kg
